| 1. Usable area | 270,49 m² |
| 2. Area garage | 40,73 m² |
| 3. Additional area | 10,14 m² |
| 4. Total surface | 585,76 m² |
| 5. Building area | 226,9 m² |
| 6. Net volume | 980,75 m³ |
| 7. Gross volume | 1190,24 m³ |
| 8. Building height | 9 m |
| 9. Roof angle | 25 ° |
| 10. Roof area | 164,81 m² |
| 11. Minimum plot size | 25,3 x 22,9 m |
| 1. Foundation footings | reinforced concrete |
| 2. Foundation walls | reinforced concrete, protected by 20 cm thick extruded styrofoam |
| 3. Exterior walls | Porotherm Dryfix ceramic hollow brick with a thickness of 30 cm by Wienerberger, insulation with Termonium styrofoam facade by Termo Organika company with a thickness of 20 cm |
| 4. Interior walls | Porotherm Profi ceramic hollow bricks by Wienerberger with a thickness of 25 cm |
| 5. Partition walls | Porotherm Profi ceramic hollow bricks by Wienerberger with a thickness of 11.5 cm |
| 6. Ceiling | reinforced concrete, monolithic |
| 7. Roof construction | wooden, insulated with rockwool with a thickness of 32 cm by Isover company |
| 8. Roofing | flat ceramic roof tile |
| 9. Facade | silicone plaster outer color: white, quartz sintered material, Trespa wood imitation facade boards |
| 10. Windows and doors | aluminum |
| 11. Type of heating | heat pump |
| 12. Ventilation | mechanical with recuperation |
| Usable area | 122,94 m2 |
| 1. Lobby | 4,78 m2 |
| 2. Corridor | 12,1 m2 |
| 3. Bathroom | 3,98 m2 |
| 4. Pantry | 3,74 m2 |
| 5. Kitchen | 19,52 m2 |
| 6. Canteen | 25,6 m2 |
| 7. Living room | 39,09 m2 |
| 8. Office | 14,13 m2 |
| 9. Garage | 40,73 m2 |
| 10. Utility room | 10,14 m2 |
| Usable area | 147,55 m2 |
| 1. Corridor | 17,76 m2 |
| 2. Bedroom | 16,71 m2 |
| 3. Wardrobe | 6,21 m2 |
| 4. Bathroom | 7,72 m2 |
| 5. Bathroom 2 | 10,97 m2 |
| 6. Bedroom 2 | 26,97 m2 |
| 7. Bedroom 3 | 19,56 m2 |
| 8. Wardrobe 2 | 3,6 m2 |
| 9. Wardrobe 3 | 15,06 m2 |
| 10. Guest room | 15,13 m2 |
| 11. Laundry room | 7,86 m2 |
Finished project is a documentation, consisting of 3 copies of architectural and construction design and technical design. It is made by authorized designers in accordance with the current rules of construction art and the latest provisions of the Construction Law.
Read more on the What does the project contain?
- Usable area 270,49 m²
- Area garage 40,73 m²
- Additional area 10,14 m²
- Total surface 585,76 m²
- Building area 226,9 m²
- Foundation footings reinforced concrete
- Foundation walls reinforced concrete, protected by 20 cm thick extruded styrofoam
- Exterior walls Porotherm Dryfix ceramic hollow brick with a thickness of 30 cm by Wienerberger, insulation with Termonium styrofoam facade by Termo Organika company with a thickness of 20 cm
- Interior walls Porotherm Profi ceramic hollow bricks by Wienerberger with a thickness of 25 cm
- Partition walls Porotherm Profi ceramic hollow bricks by Wienerberger with a thickness of 11.5 cm
