| 1. Usable area | 292,66 m² |
| 2. Additional area | 52,25 m² |
| 3. Total surface | 415,82 m² |
| 4. Building area | 310,75 m² |
| 5. Net volume | 1420 m³ |
| 6. Gross volume | 2247 m³ |
| 7. Building height | 8,98 m |
| 8. Roof angle | 30 ° |
| 9. Сeiling height | 2,70 / 3,08 m |
| 10. Minimum plot size | 27,00 x 40,25 m |
| 1. Foundation walls | Reinforced concrete, XPS polystyrene with a thickness of 20 cm and 5 cm |
| 2. Exterior walls | Porotherm Dryfix ceramic blocks with a thickness of 30 cm and 20 cm by Wienerberger, Fasada Plus polystyrene foam with a thickness of 20 cm by Termo Organika |
| 3. Interior walls | Porotherm P+W ceramic hollow block with a thickness of 25 cm and 11.5 cm by Wienerberger |
| 4. Ceiling | reinforced concrete, monolithic |
| 5. Roof construction | Roof trusses; reinforced concrete ceiling |
| 6. Roofing | standing seam metal sheet; Bauder KARAT roofing felt |
| 7. Facade | exterior silicone plaster, white color |
| 8. Windows and doors | aluminum, anthracite color |
| 9. Type of heating | underfloor heating, water-to-air heat pump |
| 10. Ventilation | mechanical with recuperation |
| Usable area | 128,21 + 115.39 m2 |
| 1. Lobby | 11,50 m2 |
| 2. Corridor | 12,47 m2 |
| 3. Kitchen | 20,40 m2 |
| 4. Pantry | 4,71 m2 |
| 5. Canteen | 22,00 m2 |
| 6. Living room | 29,04 m2 |
| 7. Corridor 2 | 5,25 m2 |
| 8. Bathroom | 8,35 m2 |
| 9. Utility room | 10,00 m2 |
| 10. Storeroom | 4,50 m2 |
| 11. Stock | 4,71 m2 |
| 12. Beauty salon | 45,66 m2 |
| 13. Waiting hall | 8,77 m2 |
| 14. Bathroom 2 | 4,00 m2 |
| 15. Garage | 52,25 m2 |
| Usable area | 101,31 m2 |
| 1. Corridor | 7,35 m2 |
| 2. Mezzanine | 11,14 m2 |
| 3. Corridor 2 | 3,31 m2 |
| 4. Wardrobe | 17,54 m2 |
| 5. Bedroom | 16,33 m2 |
| 6. Laundry room | 8,46 m2 |
| 7. Bedroom 2 | 12,45 m2 |
| 8. Bedroom 3 | 12,45 m2 |
| 9. Bathroom | 12,26 m2 |
Finished project is a documentation, consisting of 3 copies of architectural and construction design and technical design. It is made by authorized designers in accordance with the current rules of construction art and the latest provisions of the Construction Law.
Read more on the What does the project contain?
- Usable area 292,66 m²
- Additional area 52,25 m²
- Total surface 415,82 m²
- Building area 310,75 m²
- Net volume 1420 m³
- Foundation footings
- Foundation plates
- Foundation walls Reinforced concrete, XPS polystyrene with a thickness of 20 cm and 5 cm
- Exterior walls Porotherm Dryfix ceramic blocks with a thickness of 30 cm and 20 cm by Wienerberger, Fasada Plus polystyrene foam with a thickness of 20 cm by Termo Organika
- Interior walls Porotherm P+W ceramic hollow block with a thickness of 25 cm and 11.5 cm by Wienerberger
